Blast Furnace Iron Trough Castable

Different types of refractory materials can be used as per the types of iron troughs. Iron storing troughs in middle and large scale steel mills usually adopt Al-Si-C series castable. Blast Furnace Iron Trough Castable For Sale has high mechanical strength, corrosion resistance, good flowability, and can be quickly dried. Iron trough castable should also has excellent thermal shock resistance.



Get Free Quote

    Your Name (required)

    Your Email (required)

    Your Phone

    Subject

    Your Message (required)

    Blast Furnace Iron Trough Castable Physiochemical Index

    Item DCTC-1 DCTC-2 DCTC-3 DCTC-4
    Material Alumina silicon carbide carbon castable Alumina silicon carbide carbon castable Alumina silicon carbide carbon castable High alumina silicon carbide castable
    Application Main trough slag line Main trough iron line Main trough iron line Main trough slag line
    Al2O3 % 60 83 77 56.9
    SiC % 37 12 11 32
    SiO2 % 2.5 2.5 / /
    C % 1~3 1~3 2 2
    Bulk density g/cm3(1450℃,3h) 2.78 2.98 2.84 2.69
    Compression strength Mpa(1450℃,3h) 50 50 35.8 /
    Reheating linear change rate %(1450℃,2h) -0.2~0.6 -0.2~0.6 -0.2~0.6 -0.1~0.2

    Get Free Quote

      Your Name (required)

      Your Email (required)

      Your Phone

      Subject

      Your Message (required)

      Alumina Silicon Carbide Carbon Castable Characteristic

      Alumina silicon carbide carbon castable is mainly used for the casting of blast furnace iron trough. Alumina silicon carbide carbon castable’s main materials are fused corundum(or sintered corundum, special grade bauxite clinker), graphite contains 90%~95% fixed carbon, silicon carbide and so on.



      Blast Furnace Iron Trough Castable
      Blast Furnace Iron Trough Castable



      The development of self flow Al-Si-C castable brings lots of convenience for casting construction. The unit refractory consumption of per ton iron is significantly decreased with the improvement of refractory castable quality.
